Logstash set up issue

Hello,

I am struggling with my logstash set up, which doesn't seem to be connected to the ELK stack.

I cannot see Logstash under Stack Monitoring:

However, I can see my custom log data which is ingested using logstash config file in the Discover page:

Here is my logstash.yml file:

pipeline.batch.size: 125
pipeline.batch.delay: 5
node.name: dlmlogstash
path.data: /var/lib/logstash/
pipeline.id: main
pipeline.workers: 2
path.config:/etc/logstash/conf.d/

log.level: info
path.logs: /usr/share/logstash/logs/

output.Elasticsearch:
hosts: ["http://10.177.36.103:9200"]
username: "elastic"
password: "passwd"

Here is the logtstash plain log file:

:/usr/share/logstash/logs # cat logstash-plain.log
[2022-03-21T06:31:54,397][INFO ][logstash.runner ] Log4j configuration path used is: /etc/logstash/log4j2.properties
[2022-03-21T06:31:54,501][INFO ][logstash.runner ] Starting Logstash {"logstash.version"=>"8.1.0", "jruby.version"=>"jruby 9.2.20.1 (2.5.8) 2021-11-30 2a2962fbd1 OpenJDK 64-Bit Server VM 11.0.13+8 on 11.0.13+8 +indy +jit [linux-x86_64]"}
[2022-03-21T06:31:54,505][INFO ][logstash.runner ] JVM bootstrap flags: [-Xms1g, -Xmx1g, -XX:+UseConcMarkSweepGC, -XX:CMSInitiatingOccupancyFraction=75, -XX:+UseCMSInitiatingOccupancyOnly, -Djava.awt.headless=true, -Dfile.encoding=UTF-8, -Djruby.compile.invokedynamic=true, -Djruby.jit.threshold=0, -Djruby.regexp.interruptible=true, -XX:+HeapDumpOnOutOfMemoryError, -Djava.security.egd=file:/dev/urandom, -Dlog4j2.isThreadContextMapInheritable=true, --add-opens=java.base/java.security=ALL-UNNAMED, --add-opens=java.base/java.io=ALL-UNNAMED, --add-opens=java.base/java.nio.channels=ALL-UNNAMED, --add-opens=java.base/sun.nio.ch=ALL-UNNAMED, --add-opens=java.management/sun.management=ALL-UNNAMED]
[2022-03-21T06:31:59,682][INFO ][logstash.agent ] Successfully started Logstash API endpoint {:port=>9600, :ssl_enabled=>false}
[2022-03-21T06:32:01,754][INFO ][org.reflections.Reflections] Reflections took 152 ms to scan 1 urls, producing 120 keys and 417 values
[2022-03-21T06:32:02,744][INFO ][logstash.javapipeline ] Pipeline main is configured with pipeline.ecs_compatibility: v8 setting. All plugins in this pipeline will default to ecs_compatibility => v8 unless explicitly configured otherwise.
[2022-03-21T06:32:02,840][INFO ][logstash.outputs.Elasticsearch][main] New Elasticsearch output {:class=>"LogStash::Outputs::Elasticsearch", :hosts=>["http://localhost:9200"]}
[2022-03-21T06:32:03,221][INFO ][logstash.outputs.Elasticsearch][main] Elasticsearch pool URLs updated {:changes=>{:removed=>, :added=>[http://elastic:xxxxxx@localhost:9200/]}}
[2022-03-21T06:32:03,578][WARN ][logstash.outputs.Elasticsearch][main] Restored connection to ES instance {:url=>"http://elastic:xxxxxx@localhost:9200/"}
[2022-03-21T06:32:03,602][INFO ][logstash.outputs.Elasticsearch][main] Elasticsearch version determined (8.1.0) {:es_version=>8}
[2022-03-21T06:32:03,604][WARN ][logstash.outputs.Elasticsearch][main] Detected a 6.x and above cluster: the type event field won't be used to determine the document _type {:es_version=>8}
[2022-03-21T06:32:03,662][INFO ][logstash.outputs.Elasticsearch][main] Config is not compliant with data streams. data_stream => auto resolved to false
[2022-03-21T06:32:03,674][WARN ][logstash.outputs.Elasticsearch][main] Elasticsearch Output configured with ecs_compatibility => v8, which resolved to an UNRELEASED preview of version 8.0.0 of the Elastic Common Schema. Once ECS v8 and an updated release of this plugin are publicly available, you will need to update this plugin to resolve this warning.
[2022-03-21T06:32:03,683][INFO ][logstash.filters.csv ][main] ECS compatibility is enabled but target option was not specified. This may cause fields to be set at the top-level of the event where they are likely to clash with the Elastic Common Schema. It is recommended to set the target option to avoid potential schema conflicts (if your data is ECS compliant or non-conflicting, feel free to ignore this message)
[2022-03-21T06:32:03,778][INFO ][logstash.outputs.Elasticsearch][main] Using a default mapping template {:es_version=>8, :ecs_compatibility=>:v8}
[2022-03-21T06:32:03,792][INFO ][logstash.javapipeline ][main] Starting pipeline {:pipeline_id=>"main", "pipeline.workers"=>2, "pipeline.batch.size"=>125, "pipeline.batch.delay"=>5, "pipeline.max_inflight"=>250, "pipeline.sources"=>["/etc/logstash/conf.d/accessinfologs.conf"], :thread=>"#<Thread:0x1a0f1697 run>"}
[2022-03-21T06:32:05,053][INFO ][logstash.javapipeline ][main] Pipeline Java execution initialization time {"seconds"=>1.26}
[2022-03-21T06:32:05,110][INFO ][logstash.javapipeline ][main] Pipeline started {"pipeline.id"=>"main"}
[2022-03-21T06:32:05,199][INFO ][logstash.agent ] Pipelines running {:count=>1, :running_pipelines=>[:main], :non_running_pipelines=>}
[2022-03-21T06:32:05,282][INFO ][filewatch.observingtail ][main][4fcf4613d7e3f499d5c8b5cbce618307f02989afad0cf42430120ed62fcae652] START, creating Discoverer, Watch with file and sincedb collections

Could you please check and let me know what i miss in my set up?

Thanks and regards,
Ashiq Aboo Backer

Hi @ashiqab ,

Have you installed metricbeat on your logstash node and enabled the logstash-xpack module ?

Hello @zx8086,

Thanks for looking into this. Yes I have metricbeat set up:

Here is my metricbeat.yml file:

metricbeat.config.modules:
path: ${path.config}/modules.d/*.yml
reload.enabled: true
reload.period: 10s
setup.template.settings:
index.number_of_shards: 1
index.codec: best_compression
name: lddbdd2
setup.kibana:
host: "10.177.36.103:5601"
output.Elasticsearch:
hosts: ["10.177.36.103:9200"]
protocol: "http"
username: "elastic"
password: "psswd"
processors:

  • add_host_metadata: ~
  • add_cloud_metadata: ~
  • add_docker_metadata: ~
  • add_kubernetes_metadata: ~
    logging.level: info
    logging.selectors: ["*"]
    logging.to_files: true
    logging.files:
    path: /var/log/metricbeat
    name: metricbeat
    keepfiles: 7
    permissions: 0644
    monitoring.enabled: true
    monitoring.Elasticsearch:

Here is my logstash-xpack.yml:

  • module: logstash
    metricsets:
    • node
    • node_stats
      xpack.enabled: true
      period: 10s
      hosts: ["10.177.36.103:9600"]
      #username: "elastic"
      #password: "passwd"

Thanks,
Ashiq

what does your metricbeat log on the Logstash node say ?

It should give you an indication if metricbeat is collecting the metric and also if it is sending it to your Elasticsearch cluster that is doing the monitoring.

Have you setup the templates for metricbeat on the Elasticsearch cluster.

Thanks dear zx8086 for directing my attention towards metricbeat log.

I was able to find the error "error making http request: Get "http://x.x.x.:9600" when I used the ip for the server. Instead when I changed to the loopback ip 127.0.0.1:9600 in logstash-xpack.yml, the error stopped and logstash is now being monitored by Metricbeat.

Thanks for your valuable feedback!

Best regards,
Ashiq
