Fixes https://github.com/elastic/kibana/issues/237845
## Summary
This PR f…ixes the "maximum tokenizer stack size reached" console error which happens when the user adds a lot of lines in the editor.
<details>
<summary>Sample input that was causing the error:</summary>
```
PUT myindex123
DELETE myindex123
PUT .kibana_test
PUT .alert_test
PUT .alerts_test
PUT myindex1234
PUT mytest
POST _aliases
{
"actions": [
{
"add": {
"index": "myindex1234",
"alias": "myindex123"
}
}
]
}
# Versioned routes: Version 1 is deprecated
GET kbn:/api/routing_example/d/versioned?apiVersion=1
GET kbn:/api/routing_example/d/versioned?apiVersion=2
# Non-versioned routes
GET kbn:/api/routing_example/d/removed_route
POST kbn:/api/routing_example/d/migrated_route
{}
GET .kibana_usage_counters/_search
{
"query": {
"bool": {
"should": [
{"match": { "usage-counter.counterType": "deprecated_api_call:total"}},
{"match": { "usage-counter.counterType": "deprecated_api_call:resolved"}},
{"match": { "usage-counter.counterType": "deprecated_api_call:marked_as_resolved"}}
]
}
}
}
PUT myindexflat
{
"mappings": {
"properties": {
"flat": {
"type": "flattened"
}
}
}
}
PUT myindexflat/_doc/123
{
"flat": [{"test": 1},{"test": 2},{"another": 1}]
}
POST myindexflat/_search
{
"fields": ["flat.test"],
"_source": false
}
POST kbn:/api/endpoint/suggestions/eventFilters
{
"query": "test",
"field": "test"
}
GET .lists-default/_search?filter_path=hits
// Should contain results from hidden index
GET my_*/_search?filter_path=hits&expand_wildcards=all,hidden
// Should be empty
GET my_*/_search?filter_path=hits
GET .my*/_search?filter_path=hits
GET .my_hidden_index/_search?filter_path=hits
GET my_hidden_index/_search?filter_path=hits
PUT .my_hidden_index/_doc/1
{
"SHOULD_NOT_BE_HERE": true
}
GET .my_sys_index
GET .my_hidden_index
GET _alias/.my_hidden_index
PUT /
# Creates a component template for mappings
PUT _component_template/my-mappings
{
"template": {
"mappings": {
"properties": {
"@timestamp": {
"type": "date",
"format": "date_optional_time||epoch_millis"
},
"message": {
"type": "wildcard"
}
}
}
},
"_meta": {
"description": "Mappings for @timestamp and message fields",
"my-custom-meta-field": "More arbitrary metadata"
}
}
# Creates a component template for index settings
PUT _component_template/my-settings
{
"template": {
"settings": {
"index.lifecycle.name": "my-lifecycle-policy"
}
},
"_meta": {
"description": "Settings for ILM",
"my-custom-meta-field": "More arbitrary metadata"
}
}
PUT _index_template/enterprise_search
{
"index_patterns": ["logs-enterprise_search*", "logs-app_search.*", "logs-workplace_search.*"],
"data_stream": { },
"composed_of": [ "my-mappings", "my-settings" ],
"priority": 500,
"_meta": {
"description": "Template for my time series data",
"my-custom-meta-field": "More arbitrary metadata"
}
}
PUT _data_stream/logs-enterprise_search.whathaveyou
PUT _data_stream/logs-app_search.whathaveyou
PUT _data_stream/logs-workplace_search.whathaveyou
GET _migration/deprecations
POST my-data-stream/_doc
{
"@timestamp": "2099-05-06T16:21:15.000Z",
"message": """192.0.2.42 - - [06/May/2099:16:21:15 +0000] "GET /images/bg.jpg HTTP/1.0" 200 24736""",
"object": {
"this": "might work",
"array": [{ "test": 1 }, { "test": 2 } ]
}
}
GET my-data-stream/_search
{
"runtime_mappings": {
"object.array.test2": {
"type": "long",
"script": {
"source": """
if (params._source.object != null && params._source.object.array != null) {
def arr = params._source.object.array;
for (def entry : arr) {
emit(entry.test + 10)
}
return;
}
"""
}
},
"messageV2": {
"type": "text",
"script": {
"source": """
if (params._source["messageV2"] != null) {
// return what we have in source if there is something
emit(params._source["messageV2"]);
} else {
// return the original processed in some way
emit(doc['message'].value + " the original, but processed");
}
"""
}
}
},
"query": {
"match_all": {}
},
"fields": ["messageV2", "object.array.test2"]
}
GET _index_template/my-index-template
GET _data_stream/my-data-strea
PUT _data_stream/my-data-stream-2
GET _data_stream/my-data-stream
GET _data_stream/my-data-stream-2
GET _data_stream/
GET .ds-my-data-stream-2025.08.13-000001/_mapping
PUT .ds-my-data-stream-2025.08.13-000001/_mapping
{
"_data_stream_timestamp": {
"enabled": true
},
"properties": {
"@timestamp": {
"type": "date",
"format": "date_optional_time||epoch_millis"
},
"message": {
"type": "wildcard"
},
"messageV2": {
"type": "text",
"fields": {
"keyword": {
"type": "keyword",
"ignore_above": 256
}
}
},
"object": {
"properties": {
"array": {
"properties": {
"test": {
"type": "long"
}
}
},
"this": {
"type": "text",
"fields": {
"keyword": {
"type": "keyword",
"ignore_above": 256
}
}
}
}
},
"test": {
"type": "text",
"fields": {
"keyword": {
"type": "keyword",
"ignore_above": 256
}
}
}
}
}
PUT _index_template/my-index-template
{
"index_patterns": [
"my-data-stream*"
],
"composed_of": [
"my-mappings",
"my-settings"
],
"priority": 500,
"_meta": {
"my-custom-meta-field": "More arbitrary metadata",
"description": "Template for my time series data"
},
"data_stream": {
"hidden": false,
"allow_custom_routing": false
}
}
```
</details>
**Root Cause:**
The xjson lexer rules inherited from `buildXjsonRules()` used Monaco's `@push` and `@pop` state management for
opening/closing braces (`{` and `}`). When Console displayed multiple requests sequentially (e.g., `GET
/index`, `POST /data {...}`, `PUT /data {...}`), the tokenizer would push a new state for each opening brace
but never properly pop back to the root state between requests. This caused stack accumulation,
eventually exceeding Monaco's tokenizer stack limit.
**The Fix:**
The fix overrides the brace handling rules in `json_root` to avoid using `@push/@pop`:
1. When a `}` appears at the end of a line, it explicitly
transitions back to the 'root' state, ensuring clean state boundaries between requests.
2. The `{` token is treated as a simple token without pushing state onto
the stack.
3. The original xjson brace rules (which used @push/@pop) are filtered out
before including the remaining `xjson` rules.
